AGV (Automatic Guided Vehicle) Series
What are Automated guided vehicles ?
Automated Guided Vehicles (AGVs) transport and store a wide range of products and materials in a variety of industries and operations — factories, warehouses, distribution centers, and shipping areas. AGVs are a safe and secure way to increase process efficiency and improve business profitability.
AGV systems operate autonomously, eliminating human errors that can cause costly damages and mistakes when picking and loading. Individual AGVs are exchangeable, which ensures redundancy in system operation.
AGV systems integrate with higher-level enterprise resource planning (ERP) systems, manufacturing execution systems (MESs), and warehouse execution systems (WESs). They can in combination with other materials handling systems like conveyors, stacker cranes, and palletizing or packing machine
Is an AGV system right for your business ?
AGV systems follow configurable paths to optimize storage, picking, and transport functions in a wide variety of environments.
Ideal applications for AGV systems include:
- Repetitive transport applications
- Multishift and 24/7 operations
- Transport to and from automated warehouses, work-in-process (WIP), and production operations
- High-velocity throughput
- Complex production flows
- Operations that have many different buffer locations
What are the benefits of AGV Systems?
- Rapid implementation and start-up
- Significantly lower operating costs than manual alternatives
- Increased productivity and efficiency
- Reduced labor requirements
- Significantly decreased product damage
- Enhanced product traceability
- Better space utilization
- Improved dispatch and shipping accuracy
Application industry
manufacturing industry
Warehouse and Logistics
Automotive Industry
Electronics Industry
Supermarkets
Ports and Piers
Automated guided vehicles Parameters
| NO. | Description | Parameters |
|---|---|---|
| 1 | Standard load | ≤3.5T (500mm Load center distance) |
| 2 | Operation place | indoor |
| 3 | Vehicle size | ≤L3500*W1300*H2500(mm) |
| 4 | Navigation mode | Multi-source fusion position navigation（2D/3DSLAM+IMU+ odometer, support RTK） |
| 5 | Control mode | Autonomous, handle, background |
| 6 | Power supply mode | Lithium battery |
| 7 | Battery capacity | ≥48V，400AH |
| 8 | Endurance time | ≥6H |
| 9 | Charging mode | Support autonomous charging, some support manual charging |
| 10 | Indoor positioning accuracy | ±20mm |
| 11 | Minimum turning radius | ≥2300mm(3.5T） |
| 12 | Maximum full load travel speed | ≥1200mm/s |
| 13 | Maximum no-load travel speed | ≥2000mm/s |
| 14 | Obstacle clearance height | 30mm(Solid rubber wheel) |
| 15 | Obstacle clearance width | ≥50mm(Solid rubber wheel） |
| 16 | Full load climbing capability | ≥6%（indoor） |
Automated guided vehicles Feature
Superior Mobility and Versatility
Designed for a wide range of tasks, offering enhanced adaptability to various work environments.
Reliable and Convenient Charging
The side-positioned automatic charging system provides hassle-free, reliable charging, ensuring minimal downtime.
Long-lasting, Efficient Power
Powered by a large capacity lithium battery, offering extended operational time and long battery life, reducing the frequency of battery changes.
Precision Navigation and Safety
Laser navigation ensures accurate positioning, while automatic deceleration and obstacle detection improve workplace safety.
Optimized Maintenance for Greater Uptime
The easy-to-access side battery and intelligently placed electronic components make maintenance faster and more efficient, keeping operations running smoothly.
High Performance with Advanced Lifting Capabilities
The vehicle’s high-power AC system, combined with fork tilt and a maximum lifting height of 5500mm, boosts productivity and operational efficiency.
Key Features and Benefits of the Lifting Mobile Robot
- Designed for multi-scenario autonomous transport.
- Compact size with a large load capacity.
- Maximum load capacity reaches up to 1,500kg.
- Suitable for a wide range of applications, including various industrial environments.
- Enables the creation of unmanned intelligent workshops for improved efficiency and automation.
Advantages of the Lifting Mobile Robot
Smart Scheduling and High-Efficiency Transport
Optimizes logistics with intelligent dispatch and fast, effective transport.
Automated Handling for Improved Productivity
Reduces manual labor and streamlines operations.
Multi-System Compatibility and Centralized Control
Integrates easily with other systems and enables unified management.
Advanced Safety Features for Secure Operations
Equipped with multiple safety protections to ensure safe handling.
Lifting Mobile Robot Parameters
| NO. | Description | Parameters |
|---|---|---|
| 1 | Overall dimension | 980*680*245 mm |
| 2 | Rated load | 1,000 kg |
| 3 | Maximum load | 1,500 kg |
| 4 | Navigation mode | Laser SLAM/ QR Code |
| 5 | Endurance time | ≥8h |
| 6 | Maximum operating speed | 1.5m/s (unloaded) |
| 7 | Lifting height | 55 mm |
| 8 | Communication mode | WIFI/ Bluetooth / 4G |
| 9 | Width of straight roadway | 710 mm |
| 10 | Rotating diameter | 1,017mm |
application projects of the Lifting Mobile Robot
